Product Specifications
| Part Number |
TIC-L003-11 |
| AutomDX |
YES |
| Bst Circuit |
YES |
| Configuration RX |
T,C |
| Configuration TX |
T,C |
| Contact Mating Area Plating |
GOLD 6u"/15u"/30u" |
| Cores Per Port |
4 |
| Diodes |
NO DIODES |
| LED Option |
WithOUT LEDS |
| Latch |
DOWN |
| Number of Ports |
1X1 |
| PCB |
FR4 |
| PCB Mount Angle |
SIDE ENTRY |
| PCB Retaining Post |
T POST |
| Pin Type |
THT SOLDER |
| RoHS Compliant |
YES-RoHS-5 With LEAD IN SOLDER EXEMPTION |
| Search |
YES |
| Shield EMI Tabs |
With OR WithOUT |
| Speed |
10/100 BASE-T |
| Temperature |
0 TO 70°C/-40 TO 85°C |
| Turns Ratio RX |
1CT:1 |
| Turns Ratio TX |
1CT:1 |
Why Choose Us
A Leading Supplier Of Integrated RJ45 Connector And Discrete Magnetic Transformers
Professional Certification
- ISO 9001:2008
- UL Certification
- Reach Certification
- RoHS Compliance
- Active Environmental Policy
100% Quality Guarantee
- Manufactured Under Strict Controls.
- 100% Tested (Not Just Batch Tested)
- Quality Guarantee: 6 Years
Competitive Price & Service
- More Competitive Pricing Options
- Delivery Time: 2-3 Weeks After Orders
- Free Samples Are Available
- Provide New Design For Customer Requirements
- Highly Discounted Shipping Costs
Corporate Policy
- Achieve The Highest Level Of Customer Satisfaction Through Continuous Improvements In Quality, Delivery And Service
- Committed To Quality Performance From Every Employee
- Company Standard Is Defect-Free Products And Services
Technical Drawings & Dimensions
Frequently Asked Questions (FAQ)
What are the plating options for the contact mating area of the TIC-L003-11?
The modular plug supports different thickness levels of gold plating in the contact mating area, including 6u", 15u", and 30u", depending on your application requirements.
What speed range does this female RJ45 modular plug support?
The TIC-L003-11 RJ45 connector is designed for standard 10/100 BASE-T network transmission speeds.
Does this connector include integrated LEDs or diodes?
No, this specific model (TIC-L003-11) is configured without LEDs and does not contain internal diodes.
What is the operating temperature range for the TIC-L003-11?
This connector is built to perform in operating temperatures ranging from 0 to 70°C, with storage/extended capabilities from -40 to 85°C.
What mounting style and latch orientation does this product feature?
It features a side-entry PCB mounting angle, a Down latch configuration, a T-post retaining design, and is secured via Through-Hole Technology (THT) soldering.
Is the TIC-L003-11 RJ45 connector RoHS compliant?
Yes, it is RoHS-5 compliant with lead-in solder exemption, ensuring compatibility with environmental safety standards.
