| Item | RJ45 Female Connector |
| Bothhand Part Number | LJ-H17S4I-00-F LJ-H17S4H-YA-F LJ-H17S4H-Y7-F |
| Part Status | Active |
| Connector Type | Jack |
| Number of Positions/Contacts | 8p8c (RJ45, Ethernet) |
| Application-Lan | Ethernet(NoN PoE) |
| Number of Ports | 1x1 Port |
| Speed | 10/100 Base-T |
| Cores per Port | 4 |
| Orientation | 90° Angle (Right) |
| PCB Mount Angle | SIDE ENTRY |
| Shield EMI Tabs | With |
| LED Option | Green/Yellow |
| PCB | FR4 |
| PCB Retaining Post | T POST |
| Temperature | 0℃ TO 70℃ |
| Bst Circuit | Yes |
| AutomDX | YES |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
| Turns Ratio RX/TX | 1CT:1CT |
| Configuration RX/TX | T,C |
We are a specialized manufacturer of magnetic telecom and networking components, such as RJ45 connectors, LAN transformers, RJ11 connectors, and SFP modules.
Yes, we can offer you free samples to test quality, but you should pay the shipping fee.
Ready to ship for stock items, and 15-30 days for mass production orders.
We provide a one-year guarantee period along with 24-hour online technical support.
Yes, please send an inquiry to us so that we can have a detailed discussion about your custom requirements.
19 years of professional production experience and stable partnerships with global leading technology firms.
