| Specifications | Details |
|---|---|
| Item | RJ45 Female Connector |
| Part Number | LPJE702NNL |
| Part Status | Active |
| Connector Type | Jack |
| Number of Positions/Contacts | 6p6c (RJ11, Ethernet) |
| Application-Lan | Ethernet (Non-PoE) |
| Number of Ports | 1x1 Port |
| Latch | Up |
| Orientation | 90° Angle (Right) |
| PCB Mount Angle | SIDE ENTRY |
| Shield EMI Tabs | Without |
| LED Option | Without |
| PCB | FR4 |
| PCB Retaining Post | T POST |
| Temperature | -40℃ TO 85℃ |
| Bst Circuit | Yes |
| AutomDX | YES |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
| Turns Ratio RX/TX | 1CT:1CT |
| Configuration RX/TX | T, C |
We are a specialized manufacturer of magnetic telecom and networking components, including RJ45 connectors, LAN transformers, RJ11 connectors, and SFP modules.
Yes, we can offer you free samples to test quality, but the shipping fee needs to be paid by the customer.
Ready stock items are available for immediate shipment. For mass production, the delivery time takes approximately 15-30 days.
We provide a one-year guarantee period along with 24-hour online technical support.
Yes, please send your inquiries and specifications to us so that we can have a detailed discussion about your customization needs.
With over 19 years of professional production experience, we have established long-term partnerships with leading global enterprise brands.
