Equip-Link
Equip-Link
| Part Number | 0845-2D1T-H5 / 0845-2D1T-S4 / RM3-ZZ-0020 |
| Application-LAN | ETHERNET(NON PoE) |
| AutomDX | YES |
| Bst Circuit | YES |
| Configuration RX | T,C |
| Configuration TX | T,C |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
| Cores Per Port | 4 |
| Diodes | NO DIODES |
| LED Option | Yellow/Green LEDS |
| Latch | UP/Down |
| Number of Ports | 2x1 Port |
| PCB | FR4 |
| PCB Mount Angle | SIDE ENTRY |
| PCB Retaining Post | T POST |
| Pin Type | THT SOLDER |
| RoHS Compliant | YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION |
| Search | YES |
| Shield EMI Tabs | With |
| Speed | 10/100 Base-T Magnetics |
| Temperature | -40 TO 85°C / 0 TO 70°C |
| Turns Ratio RX | 1CT:1 |
| Turns Ratio TX | 1CT:1 |
World’s Leader Supplier Of Integrated RJ45 Connector And Discrete Magnetic Transformers
Preferred Supplier for Leading Tech Brands
Providing high-reliability magnetic components and RJ45 jacks compatible with major development platforms.
A: These connectors are specifically designed for 10/100 Base-T ETHERNET (Non-PoE) applications, featuring a 2-port 8P8C modular jack configuration.
A: They support two operating temperature configurations: standard industrial range from -40°C to 85°C, or commercial range from 0°C to 70°C.
A: Yes, they are equipped with Yellow/Green LEDs for status indication and include built-in EMI tabs for enhanced shielding performance.
A: The manufacturing process complies with ISO 9001:2008 standards, UL Certification, REACH Certification, and RoHS Compliance with lead-in-solder exemption.
A: Yes, free samples are available to test. The standard delivery timeline for bulk orders is approximately 2 to 3 weeks after confirmation.
A: The gold plating thickness on the contact mating area is customizable, with options including 6u", 15u", or 30u" gold thickness.
