Specification
| Specification item |
Specification value |
| Manufacturer Part Number |
LPJ26404AENL |
| Pulse Part Number |
JXD0-2005NL / JXR8-1001NL |
| Part Status |
Active |
| Connector Type |
RJ45 |
| Applications-Lan |
Ethernet(Non_PoE) |
| Speed |
10/100 Base-T, AutoMDIX |
| Mounting Type |
Through Hole |
| Orientation |
90° Angle (Right) |
| Termination |
Solder |
| Contact Finish Thickness |
6.00µin (0.152µm) |
| LED Color |
Green/Yellow Led |
| Number of Cores per Jack |
4 |
| Shielding |
Shielded, Emi Finger |
| Number of Ports |
1x2 Port |
| Features |
Board Guide |
| Tab Direction |
Down |
| Contact Finish |
Gold |
| Configuration RX/TX |
T,C |
| Turns Ratio RX/TX |
1CT:1CT |
| Operating Temperature |
-40°C ~ 85°C |
We are a specialized manufacturer of magnetic telecom and networking components, certified by ISO9001:2000, RoHS, REACH, CE and UL. Equipped with advanced manufacturing facilities and testing instruments imported from abroad, we maintain a robust production capacity of 3000K units per month to ensure swift delivery. We offer professional, complete solutions for magnetic components alongside strong technical support. Our products are widely implemented in networking and communication systems, including hubs, PC cards, switches, routers, PC mainboards, SDH, PDH, IP Phones, and xDSL modems.
Main Product Categories:
- 10/100/1000M/2.5G/5G/10G LAN pulse transformer and filter
- RJ45 connector with 10/100/1000M/2.5G/5G/10G magnetics
- T1/E1, T3/DS3/E3/STS-1 interface line transformer
- ISDN, HDSL, ADSL and VDSL interface line transformer and splitter
Frequently Asked Questions
Are you a manufacturer or a trading company?
We are a dedicated manufacturer specializing in RJ45 connectors and LAN Transformers for over 23 years.
Can I request product samples?
Yes, we provide 3-5 free samples for testing purposes. Small batch orders are also welcome.
Do you offer OEM/ODM services?
Yes, we have extensive experience translating custom designs and technical requirements into finished products, including custom brand laser marking.
What is the standard production lead time?
Through our efficient production workflows, standard shipments are typically processed within 30 days.
What speed standards and LAN applications are supported?
This component supports 10/100 Base-T Ethernet speeds with AutoMDIX functionality and is suitable for non-PoE network architectures.
What is the operating temperature range for this RJ45 connector?
The connector is designed to operate reliably across a temperature range of -40°C to 85°C.
