| Item | Value |
| Manufacturer Part Number | LPJ46404AENL |
| Compatible Part Number | JXD0-4005NL / JX80-0033NL |
| Part Status | Active |
| Connector Type | RJ45 |
| Applications-Lan | Ethernet(Non_PoE) |
| Speed | 10/100 Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Contact Finish Thickness | 6.00µin (0.152µm) |
| LED Color | Green/Yellow Led |
| Number of Cores per Jack | 4 |
| Shielding | Shielded, Emi Finger |
| Number of Ports | 1x4 Port |
| Features | Board Guide |
| Tab Direction | Down |
| Contact Finish | Gold |
| Configuration RX/TX | T,C |
| Turns Ratio RX/TX | 1CT:1CT |
| Operating Temperature | -40°C ~ 85°C |
We are a manufacturer specialized in RJ45 connectors and LAN Transformers for more than 23 years.
Yes, 3-5 pcs free samples are available for your test. Small batches are also acceptable.
Yes. We have rich experience and good capability to put your design and idea into real products, including laser printing your brand on the products.
We have a very professional production team maintaining high-quality outputs. Usually, standard shipments can be fulfilled within 30 days. Please reach out to our representatives for detailed arrangements.
Our products are widely used in networking and communication equipment such as HUBs, PC cards, Switches, Routers, PC Mainboards, SDH, PDH, IP Phones, and xDSL modems.
The component is designed to operate reliably within a temperature range of -40°C to 85°C, making it suitable for both standard and industrial-grade applications.
